Ce
425, 450, 465, 485, 500, 510, 520, 525, 540, 560, 600
-
Cc
430, 465, 500, 515, 530, 540, 550, 560, 575, 595, 620
-
L
505, 515, 525, 535, 545, 552, 557, 565, 575, 595, 620
-
A [°]
74.4, 74.4, 74, 73.7, 73.7, 73.4, 73.4, 73, 73, 72.4, 72
-
B [°]
70, 70, 70.5, 71, 71.5, 72, 72, 72.5, 72.8, 73, 73
-
P
422, 422, 422, 422, 422, 422, 422, 422, 422, 422, 422
-
T
107, 119, 124, 129, 138, 146, 157, 165, 178, 214, 254
-
D
77, 77, 77, 77, 77, 77, 77, 77, 77, 72, 72
-
R
47, 47, 47, 47, 47, 47, 47, 47, 47, 47, 47
-
G
375, 375, 375, 375, 375, 375, 375, 375, 375, 375, 375
-
Reach
349.3, 358.1, 365.4, 371.7, 379.4, 381.2, 383, 384.6, 390.8, 395.3, 403.8
-
Stack
524.2, 535.5, 542.1, 548.6, 559, 568.4, 578.9, 588.4, 601.7, 632, 670.3
-
Wb
966.8, 979.7, 986.8, 990.6, 997, 999.1, 1004.3, 1003.9, 1011.7, 1025.3, 1047.6
-
Frame
TorayCa T1100 1K Dream Carbon with Nanoalloy technology, internal cable routing, Italian BB, UCI approved
-
Crankset and chainrings
Shimano Dura Ace Di2 RD-R9200 12s
-
Front derailleur
Shimano Dura Ace Di2 FD-9200 12S
-
Rear derailleur
Shimano Dura Ace Di2 RD-R9200 12s
-
Cassette
Shimano Dura Ace CS-R9200 12S
-
Chain
Shimano Dura Ace CN-HG 12S
-
Bottom bracket
Shimano Dura Ace SM-BB9200
-
Front brake disk
Dura Ace BR-R9200, 2 pistons caliper, 160mm rotor
-
Rear brake disk
Dura Ace BR-R9200, 2 pistons caliper, 140mm rotor
-
Integrated handlebar
MOST Talon Ultra Light
-
Saddle
Most Lynx Ultrafast Superflow L Carbon Large 145mm
-
Seatpost
Pinarello Aero seatpost with 3D printed titanium top seatclamp and bolts
-
Seat clamp
Seatclamp Twinforce, titanium bolts
-
Tires disk
Pirelli P ZERO Race TLR 35-622
-
Wheelset disk
PRINCETON GRIT 4540 DB
-
Axles disk
Ultra Light Custom Axle 12x100 & 12x142, tool free removal
-
Bottles and bottle cages
Bottlecage Trap PACF ø 74mm, Fly Bottle Pinarello Bottle 550ml Black
-
Additional availability note
Also available with DTSWISS ERC1400
-
Frame sizes
11, 11, 9
-
Groupset
DURA ACE Di2, DURA ACE Di2, SHIMANO DURA ACE Di2
-
Wheelset disk (Compare Models)
PRINCETON GRIT 4540 DB, PRINCETON GRIT 4540 DB, MOST Ultrafast 40*
